Flexible Duct Connector Machine


Technical Data
GS Strip thickness 0.4-0.6mm
GS Strip width 50-130mm
Fireproof fabric strip width 80-630mm
Final production strip width 120-750mm

Power
Main 3kw (Inverter motor)
Hydraulic station 5.5kw
Servo motor 1.5kw
Speed 0-8m/min
Weight 3600kg
Dimension Main machine: 3000*1500*1600mm        1pc
Decoiler: 1100*1100*1100mm                  2pcs
Receiving machine: 1100*750*1100mm   1pc
Punchine rack: 1000*1000*1200mm        1pc

Configuration
1.Holes punched by the hydraulic unit
2.Hydraulic driven auto cutting
3.Encoder from Japanese OMRON
4.PLC &frequency converter from DELTA
5.Electrical equipment from Schneider
6.All hydraulic cylinder and accessory from Taiwan
7.Main control box and electric box: Siemens
8.Decoiler(Load:<800kg)           2 sets
   Hydraulic servo feeder             1 sets
   Hydraulic punching moulds      2 sets
   Main machine                           1 set
   Receiving rack                          1 set
